Key Specs

• Wrap-around handle allows for multiple caregiver access to maneuver
• Smart Monitor technology drives user compliance and lift longevity
• Intuitive push pad assists with initiating movement
• Swan neck style legs allow Calibre to get closer to the resident
• Weight scale comes standard

• Safe Working Load 850 lbs/386kg

Bariatric Feature Set Developed  with the Caregiver in Mind

Safe Working Load: 850 lbs / 386 kg
Maximum Overall Length: 64 in / 1626 mm
Reach at Maximum Height: 28 in / 711 mm
Reach at Minimum Height: 26 in / 660 mm
Maximum Reach*: 37 in / 940 mm
Legs Open – External Width: 55.25 in / 1403 mm
Legs Open - Internal Width: 49.0" / 1245 mm
Legs Closed – External Width: 33.25 in / 845 mm
Legs Closed - Internal Width: 26.8" / 680 mm
Tested to: EN ISO 10535, the global standard for patient lifts

WEIGHTS
Mast, Base and Boom Assembly: 240.3 lb
Power Pack: 6.6 lb
Total: 246.9 lb
6-Point Cradle: 19.8 lb

We take pride in the lasting quality of our products. Your product is backed by a comprehensive warranty designed to give you confidence and peace of mind.

Aluminum structural components (frame, welds) & main mechanical parts: 5‑year warranty.

Mechanical & electrical components: 2‑year warranty.

Wear parts (e.g. batteries, casters, hydraulic pumps): 90‑day warranty.
